AS400-2A1
4U 2-Socket, NVIDIA RTX PRO™ Server for Enterprise AI Factory
8-GPU PCIe
- ⦁ Up to 8 dual-slot PCIe GPUs
Support NVIDIA H200 NVL, RTX PRO™ 6000 Blackwell Server Edition, and L40S - ⦁ Dual AMD EPYC™ 9005 Series Processors, TDP up to 400W
- ⦁ 32x DDR5 DIMM slots, up to 6400 MT/s
- ⦁ 8x E1.S NVMe
- ⦁ 5x PCIe 5.0 x16 SS FHFL for
1x NVIDIA BlueField®-3 DPU and 4x NVIDIA ConnectX®-7 NICs - ⦁ 3+1 2700W Titanium CRPS
- ⦁ Support 8 slots CXL® 2.0
Key Features
- 1. Up to 8 dual-slot PCIe GPUs
Support NVIDIA H200 NVL, RTX PRO™ 6000 Blackwell Server Edition, and L40S - 2. Dual AMD EPYC™ 9005 Series Processors, TDP up to 400W
- 3. 32x DDR5 DIMM slots, up to 6400 MT/s
- 4. 8x E1.S NVMe
- 5. 5x PCIe 5.0 x16 SS FHFL for
1x NVIDIA BlueField®-3 DPU and 4x NVIDIA ConnectX®-7 NICs - 6. 3+1 2700W Titanium CRPS
- 7. Support 8 slots CXL® 2.0
| AS400-2A1 | ||
| Chassis Form Factor | MGX 4U | |
| Chassis Dimension (mm) | 440 (W) x 176 (H) x 800 (D) | |
| Mainboard Form Factor | MGX Board | |
| Mainboard Dimension (mm) | 424.5 x 305.59 | |
| Per Node Specifications | ||
| Processor | Number of Processors | 2 |
| Processor Type | AMD EPYC™ 9005 Processor | |
| Max. TDP Support | 400W | |
| GPU |
Up to 8 DS PCIe GPU up to 600W (NVIDIA H200 NVL, RTX PRO™ 6000, L40S) Up to 16 SS PCIe GPU up to 300W |
|
| Memory | Total Slots | 32 x DIMM slots |
| Memory Type | DDR5 RDIMM (6400MT/s rated): 1DPC: 5200MT/s (1R/2R) 2DPC: 4400 MT/s (1R) / 4000 MT/s (2R) |
|
| DIMM Capacity (GB per DIMM) |
32GB, 64GB, 128GB | |
| Expansion Slots | SKU -#1 | 5x PCIe 5.0 x16 SS FHFL: For NVIDIA BlueField®-3 & ConnectX®-7 card |
| Storage Bays | SKU -#1 | 8x E1.S NVMe |
| Onboard Storage | 2x M.2 2280/22110 NVMe | |
| Management | DC-SCI BMC Management (Aspeed® AST2600) | |
| Security |
TPM 2.0 PROT (optional) |
|
| Networking Interface | 1x IPMI RJ45 | |
| Front I/O Ports |
1x IPMI RJ45 1x MiniDP 1x USB 3.2 Gen 1 1x Micro USB COM Port 1x Power button LED |
|
| OS Support |
Red Hat Enterprise Linux 9.2 or later Ubuntu 22.04 LTS |
|
| Other Specifications per System/Chassis | ||
| Power Supply | 3+1 3200W Titanium CRPS | |
| Fans | 10 x 8080 Fans | |
| Operating Environment |
Ambient operating temperature range: 5°C to +35 °C Ambient Non-operating temperature: -40°C to +68 °C Operating relative humidity: 10% to 90%, noncondensing Non-operating relative humidity: up to 93%, noncondensing |
|
| Conformity Country List |
North America: UL (Safety) / FCC (EMC) EU: CB (Safety) / CE (EMC) Taiwan: BSMI |
|
